SMA connectors are subminiature, 50-ohm precision components with ¼”-36 threaded coupling, ideal for semi-rigid cables up to 18 GHz and flexible cables to 12.4 GHz. Available in extended-frequency, MIL-PRF-39012 qualified, and commercial E-Line versions, each connector is engineered for high performance, easy assembly, and versatile packaging requirements.
For detailed specifications and dimensions, please Contact us
Custom solutions are always available.
| Equivalent Part Number url | Series | Type | Part Number | Impedance (ohm) | Frequency Range | Voltage Rating (RMS) Max | Dielectric Withstanding Voltage (VRMS) MAX | Dimensions (Based on Drawing) A | Dimensions (Based on Drawing) B | Dimensions (Based on Drawing) C | Plating Body | Contact |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| M39012/55-3006 | SMA | Straight Plug | SMA-SP-1 | 50 | DC – 18 GHz | 500 | 1.000 | 91,00 | 67,00 | — | Gold | Gold |
| M39012/55-3007 | SMA | Straight Plug | SMA-SP-2 | 50 | DC – 18 GHz | 500 | 1.000 | 91,00 | 67,00 | — | Gold | Gold |
| M39012/55-3008 | SMA | Straight Plug | SMA-SP-3 | 50 | DC – 18 GHz | 500 | 1.000 | 94,00 | 57,00 | — | Gold | Gold |
| M39012/55-3009 | SMA | Straight Plug | SMA-SP-4 | 50 | DC – 18 GHz | 500 | 1.000 | 94,00 | 57,00 | — | Gold | Gold |
| M39012/55-3025 | SMA | Straight Plug | SMA-SP-5 | 50 | DC – 18 GHz | 500 | 1.000 | 91,00 | 67,00 | — | Passivated | Gold |
| M39012/55-3026 | SMA | Straight Plug | SMA-SP-6 | 50 | DC – 18 GHz | 500 | 1.000 | 97,00 | 67,00 | — | Passivated | Gold |
| M39012/55-3027 | SMA | Straight Plug | SMA-SP-7 | 50 | DC – 18 GHz | 500 | 1.000 | 94,00 | 57,00 | — | Passivated | Gold |
| M39012/55-3028 | SMA | Straight Plug | SMA-SP-8 | 50 | DC – 18 GHz | 500 | 1.000 | 95,00 | 57,00 | — | Passivated | Gold |
| M39012/55-3029 | SMA | Straight Plug | SMA-SP-9 | 50 | DC – 18 GHz | 500 | 1.000 | 97,00 | 57,00 | — | Passivated | Gold |
| M39012/55-3030 | SMA | Straight Plug | SMA-SP-10 | 50 | DC – 18 GHz | 500 | 1.000 | 91,00 | 67,00 | — | Gold | Gold |
| M39012/55-3106 | SMA | Straight Plug | SMA-SP-11 | 50 | DC – 18 GHz | 500 | 1.000 | 91,00 | 67,00 | — | Gold | Gold |
| M39012/55-3107 | SMA | Straight Plug | SMA-SP-12 | 50 | DC – 18 GHz | 500 | 1.000 | 91,00 | 67,00 | — | Gold | Gold |
| M39012/55-3108 | SMA | Straight Plug | SMA-SP-13 | 50 | DC – 18 GHz | 500 | 1.000 | 94,00 | 57,00 | — | Gold | Gold |
| M39012/55-3109 | SMA | Straight Plug | SMA-SP-14 | 50 | DC – 18 GHz | 500 | 1.000 | 94,00 | 57,00 | — | Gold | Gold |
| M39012/55-3125 | SMA | Straight Plug | SMA-SP-15 | 50 | DC – 18 GHz | 500 | 1.000 | 91,00 | 67,00 | — | Passivated | Gold |
| M39012/55-3126 | SMA | Straight Plug | SMA-SP-16 | 50 | DC – 18 GHz | 500 | 1.000 | 97,00 | 57,00 | — | Passivated | Gold |
| M39012/55-3127 | SMA | Straight Plug | SMA-SP-17 | 50 | DC – 18 GHz | 500 | 1.000 | 94,00 | 57,00 | — | Passivated | Gold |
| M39012/55-3128 | SMA | Straight Plug | SMA-SP-18 | 50 | DC – 18 GHz | 500 | 1.000 | 95,00 | 57,00 | — | Passivated | Gold |
| M39012/55-3129 | SMA | Straight Plug | SMA-SP-19 | 50 | DC – 18 GHz | 500 | 1.000 | 97,00 | 57,00 | — | Passivated | Gold |
| M39012/55-3130 | SMA | Straight Plug | SMA-SP-20 | 50 | DC – 18 GHz | 500 | 1.000 | 91,00 | 67,00 | — | Gold | Gold |
| M39012/55-4006 | SMA | Straight Plug | SMA-SP-21 | 50 | DC – 18 GHz | 500 | 1.000 | 125,00 | 67,00 | — | Gold | Gold |
| M39012/55-4007 | SMA | Straight Plug | SMA-SP-22 | 50 | DC – 18 GHz | 500 | 1.000 | 125,00 | 67,00 | — | Gold | Gold |
| M39012/55-4008 | SMA | Straight Plug | SMA-SP-23 | 50 | DC – 18 GHz | 500 | 1.000 | 125,00 | 67,00 | — | Gold | Gold |
| M39012/55-4009 | SMA | Straight Plug | SMA-SP-24 | 50 | DC – 18 GHz | 500 | 1.000 | 94,00 | 568,00 | — | Gold | Gold |
| M39012/55-4030 | SMA | Straight Plug | SMA-SP-25 | 50 | DC – 18 GHz | 500 | 1.000 | 94,00 | 568,00 | — | Gold | Gold |
| M39012/55-4106 | SMA | Straight Plug | SMA-SP-26 | 50 | DC – 18 GHz | 500 | 1.000 | 125,00 | 67,00 | — | Gold | Gold |
| M39012/55-4107 | SMA | Straight Plug | SMA-SP-27 | 50 | DC – 18 GHz | 500 | 1.000 | 125,00 | 67,00 | — | Gold | Gold |
| M39012/55-4108 | SMA | Straight Plug | SMA-SP-28 | 50 | DC – 18 GHz | 500 | 1.000 | 94,00 | 568,00 | — | Gold | Gold |
| M39012/55-4109 | SMA | Straight Plug | SMA-SP-29 | 50 | DC – 18 GHz | 500 | 1.000 | 94,00 | 568,00 | — | Gold | Gold |
| M39012/55-4130 | SMA | Straight Plug | SMA-SP-30 | 50 | DC – 18 GHz | 500 | 1.000 | 94,00 | 568,00 | — | Gold | Gold |
| M39012/56-3006 | SMA | Right Angle Plug | SMA-RAP-1 | 50 | DC – 18 GHz | 500 | 1.000 | 68,00 | 55,00 | — | Gold | Gold |
| M39012/56-3007 | SMA | Right Angle Plug | SMA-RAP-2 | 50 | DC – 18 GHz | 500 | 1.000 | 68,00 | 55,00 | — | Gold | Gold |
| M39012/56-3008 | SMA | Right Angle Plug | SMA-RAP-3 | 50 | DC – 18 GHz | 500 | 1.000 | 76,00 | 63,00 | — | Gold | Gold |
| M39012/56-3009 | SMA | Right Angle Plug | SMA-RAP-4 | 50 | DC – 18 GHz | 500 | 1.000 | 76,00 | 63,00 | — | Gold | Gold |
| M39012/56-3025 | SMA | Right Angle Plug | SMA-RAP-5 | 50 | DC – 18 GHz | 500 | 1.000 | 68,00 | 55,00 | — | Passivated | Gold |
| M39012/56-3026 | SMA | Right Angle Plug | SMA-RAP-6 | 50 | DC – 18 GHz | 500 | 1.000 | 74,00 | 61,00 | — | Passivated | Gold |
| M39012/56-3027 | SMA | Right Angle Plug | SMA-RAP-7 | 50 | DC – 18 GHz | 500 | 1.000 | 68,00 | 55,00 | — | Passivated | Gold |
| M39012/56-3028 | SMA | Right Angle Plug | SMA-RAP-8 | 50 | DC – 18 GHz | 500 | 1.000 | 69,00 | 56,00 | — | Passivated | Gold |
| M39012/56-3029 | SMA | Right Angle Plug | SMA-RAP-9 | 50 | DC – 18 GHz | 500 | 1.000 | 71,00 | 58,00 | — | Passivated | Gold |
| M39012/56-3030 | SMA | Right Angle Plug | SMA-RAP-10 | 50 | DC – 18 GHz | 500 | 1.000 | 68,00 | 55,00 | — | Gold | Gold |
| M39012/56-3106 | SMA | Right Angle Plug | SMA-RAP-11 | 50 | DC – 18 GHz | 500 | 1.000 | 68,00 | 55,00 | — | Gold | Gold |
| M39012/56-3107 | SMA | Right Angle Plug | SMA-RAP-12 | 50 | DC – 18 GHz | 500 | 1.000 | 68,00 | 55,00 | — | Gold | Gold |
| M39012/56-3108 | SMA | Right Angle Plug | SMA-RAP-13 | 50 | DC – 18 GHz | 500 | 1.000 | 76,00 | 63,00 | — | Gold | Gold |
| M39012/56-3109 | SMA | Right Angle Plug | SMA-RAP-14 | 50 | DC – 18 GHz | 500 | 1.000 | 76,00 | 63,00 | — | Gold | Gold |
| M39012/56-3125 | SMA | Right Angle Plug | SMA-RAP-15 | 50 | DC – 18 GHz | 500 | 1.000 | 68,00 | 55,00 | — | Passivated | Gold |
| M39012/56-3126 | SMA | Right Angle Plug | SMA-RAP-16 | 50 | DC – 18 GHz | 500 | 1.000 | 74,00 | 61,00 | — | Passivated | Gold |
| M39012/56-3127 | SMA | Right Angle Plug | SMA-RAP-17 | 50 | DC – 18 GHz | 500 | 1.000 | 68,00 | 55,00 | — | Passivated | Gold |
| M39012/56-3128 | SMA | Right Angle Plug | SMA-RAP-18 | 50 | DC – 18 GHz | 500 | 1.000 | 69,00 | 56,00 | — | Passivated | Gold |
| M39012/56-3129 | SMA | Right Angle Plug | SMA-RAP-19 | 50 | DC – 18 GHz | 500 | 1.000 | 71,00 | 58,00 | — | Passivated | Gold |
| M39012/56-3130 | SMA | Right Angle Plug | SMA-RAP-20 | 50 | DC – 18 GHz | 500 | 1.000 | 68,00 | 55,00 | — | Gold | Gold |
| M39012/56-3502 | SMA | Right Angle Plug | SMA-RAP-21 | 50 | DC – 18 GHz | 500 | 1.000 | 113,00 | 101,00 | — | Passivated | Gold |
| M39012/56-3602 | SMA | Right Angle Plug | SMA-RAP-22 | 50 | DC – 18 GHz | 500 | 1.000 | 113,00 | 101,00 | — | Gold | Gold |
| M39012/56-4502 | SMA | Right Angle Plug | SMA-RAP-23 | 50 | DC – 18 GHz | 500 | 1.000 | 113,00 | 101,00 | — | Passivated | Gold |
| M39012/56-4602 | SMA | Right Angle Plug | SMA-RAP-24 | 50 | DC – 18 GHz | 500 | 1.000 | 113,00 | 101,00 | — | Gold | Gold |
| M39012/57-3006 | SMA | Straight Jack | SMA-SJ-1 | 50 | DC – 18 GHz | 500 | 1.000 | 87,00 | 63,00 | — | Gold | Gold |
| M39012/57-3007 | SMA | Straight Jack | SMA-SJ-2 | 50 | DC – 18 GHz | 500 | 1.000 | 87,00 | 63,00 | — | Gold | Gold |
| M39012/57-3008 | SMA | Straight Jack | SMA-SJ-3 | 50 | DC – 18 GHz | 500 | 1.000 | 9,00 | 53,00 | — | Gold | Gold |
| M39012/57-3009 | SMA | Straight Jack | SMA-SJ-4 | 50 | DC – 18 GHz | 500 | 1.000 | 9,00 | 53,00 | — | Gold | Gold |
| M39012/57-3025 | SMA | Straight Jack | SMA-SJ-5 | 50 | DC – 18 GHz | 500 | 1.000 | 87,00 | 63,00 | — | Passivated | Gold |
| M39012/57-3026 | SMA | Straight Jack | SMA-SJ-6 | 50 | DC – 18 GHz | 500 | 1.000 | 93,00 | 63,00 | — | Passivated | Gold |
| M39012/57-3027 | SMA | Straight Jack | SMA-SJ-7 | 50 | DC – 18 GHz | 500 | 1.000 | 91,00 | 53,00 | — | Passivated | Gold |
| M39012/57-3028 | SMA | Straight Jack | SMA-SJ-8 | 50 | DC – 18 GHz | 500 | 1.000 | 91,00 | 53,00 | — | Passivated | Gold |
| M39012/57-3029 | SMA | Straight Jack | SMA-SJ-9 | 50 | DC – 18 GHz | 500 | 1.000 | 93,00 | 53,00 | — | Passivated | Gold |
| M39012/57-3030 | SMA | Straight Jack | SMA-SJ-10 | 50 | DC – 18 GHz | 500 | 1.000 | 87,00 | 63,00 | — | Gold | Gold |
| M39012/57-4007 | SMA | Straight Jack | SMA-SJ-11 | 50 | DC – 18 GHz | 500 | 1.000 | 96,00 | 63,00 | — | Gold | Gold |
| M39012/58-3006 | SMA | Panel Jack | SMA-PJ-1 | 50 | DC – 18 GHz | 500 | 1.000 | 87,00 | 63,00 | — | Gold | Gold |
| M39012/58-3007 | SMA | Panel Jack | SMA-PJ-2 | 50 | DC – 18 GHz | 500 | 1.000 | 87,00 | 63,00 | — | Gold | Gold |
| M39012/58-3008 | SMA | Panel Jack | SMA-PJ-3 | 50 | DC – 18 GHz | 500 | 1.000 | 9,00 | 53,00 | — | Gold | Gold |
| M39012/58-3009 | SMA | Panel Jack | SMA-PJ-4 | 50 | DC – 18 GHz | 500 | 1.000 | 9,00 | 53,00 | — | Gold | Gold |
| M39012/58-3025 | SMA | Panel Jack | SMA-PJ-5 | 50 | DC – 18 GHz | 500 | 1.000 | 87,00 | 63,00 | — | Passivated | Gold |
| M39012/58-3026 | SMA | Panel Jack | SMA-PJ-6 | 50 | DC – 18 GHz | 500 | 1.000 | 93,00 | 63,00 | — | Passivated | Gold |
| M39012/58-3027 | SMA | Panel Jack | SMA-PJ-7 | 50 | DC – 18 GHz | 500 | 1.000 | 91,00 | 53,00 | — | Passivated | Gold |
| M39012/58-3028 | SMA | Panel Jack | SMA-PJ-8 | 50 | DC – 18 GHz | 500 | 1.000 | 91,00 | 53,00 | — | Passivated | Gold |
| M39012/58-3029 | SMA | Panel Jack | SMA-PJ-9 | 50 | DC – 18 GHz | 500 | 1.000 | 93,00 | 53,00 | — | Passivated | Gold |
| M39012/58-3030 | SMA | Panel Jack | SMA-PJ-10 | 50 | DC – 18 GHz | 500 | 1.000 | 87,00 | 63,00 | — | Gold | Gold |
| M39012/59-3006 | SMA | Bulkhead Jack | SMA-BHJ-1 | 50 | DC – 18 GHz | 500 | 1.000 | 87,00 | 63,00 | — | Gold | Gold |
| M39012/59-3007 | SMA | Bulkhead Jack | SMA-BHJ-2 | 50 | DC – 18 GHz | 500 | 1.000 | 87,00 | 63,00 | — | Gold | Gold |
| M39012/59-3008 | SMA | Bulkhead Jack | SMA-BHJ-3 | 50 | DC – 18 GHz | 500 | 1.000 | 9,00 | 53,00 | — | Gold | Gold |
| M39012/59-3009 | SMA | Bulkhead Jack | SMA-BHJ-4 | 50 | DC – 18 GHz | 500 | 1.000 | 9,00 | 53,00 | — | Gold | Gold |
| M39012/59-3025 | SMA | Bulkhead Jack | SMA-BHJ-5 | 50 | DC – 18 GHz | 500 | 1.000 | 87,00 | 63,00 | — | Passivated | Gold |
| M39012/59-3026 | SMA | Bulkhead Jack | SMA-BHJ-6 | 50 | DC – 18 GHz | 500 | 1.000 | 93,00 | 63,00 | — | Passivated | Gold |
| M39012/59-3027 | SMA | Bulkhead Jack | SMA-BHJ-7 | 50 | DC – 18 GHz | 500 | 1.000 | 91,00 | 53,00 | — | Passivated | Gold |
| M39012/59-3028 | SMA | Bulkhead Jack | SMA-BHJ-8 | 50 | DC – 18 GHz | 500 | 1.000 | 91,00 | 53,00 | — | Passivated | Gold |
| M39012/59-3029 | SMA | Bulkhead Jack | SMA-BHJ-9 | 50 | DC – 18 GHz | 500 | 1.000 | 93,00 | 53,00 | — | Passivated | Gold |
| M39012/59-3030 | SMA | Bulkhead Jack | SMA-BHJ-10 | 50 | DC – 18 GHz | 500 | 1.000 | 87,00 | 63,00 | — | Gold | Gold |
| M39012/59-4009 | SMA | Bulkhead Jack | SMA-BHJ-11 | 50 | DC – 18 GHz | 500 | 1.000 | 96,00 | 53,00 | — | Gold | Gold |
| M39012/60-3001 | SMA | Panel Jack Receptacle | SMA-PJR-1 | 50 | DC – 18 GHz | 500 | 1.000 | 5,00 | 34,00 | 0.102 | Passivated | Gold |
| M39012/60-3002 | SMA | Panel Jack Receptacle | SMA-PJR-2 | 50 | DC – 18 GHz | 500 | 1.000 | 625,00 | 481,00 | 0.102 | Passivated | Gold |
| M39012/61-3001 | SMA | Bulkhead Jack Receptacle | SMA-BHJR-1 | 50 | DC – 18 GHz | 500 | 1.000 | 69,00 | 415,00 | 0.062 | Passivated | Gold |
| M39012/61-3002 | SMA | Bulkhead Jack Receptacle | SMA-BHJR-2 | 50 | DC – 18 GHz | 500 | 1.000 | 69,00 | 31,00 | — | Passivated | Gold |
